Why Redis Fits Caching: Data Structures, Thread Model, and Persistence • FXJ Wiki

Covered Content#

High-frequency questions from Redis Summary
Notes on cache positioning, data structures, thread model, and persistence from Redis Common Interview Questions

Redis Knowledge Overview#

Knowledge Points#

Summarized using mind maps

Niuke Xiaoyue: High-frequency questions:

What are Redis data types? Application scenarios?
Do you understand the underlying data structures of Redis data types?
Why does ZSet use SkipList? What is SkipList?
How does Redis implement distributed locks?
What problems exist with distributed locks implemented using SetNx?
What data structure does Redisson distributed lock use?
What are the benefits of Redisson distributed locks?
Can you explain how to implement reentrancy?
Do you understand the watchdog mechanism for timeout renewal?
What are the problems with Redisson distributed locks? How to solve them?
Introduce Redis persistence methods (RDB, AOF, hybrid persistence)? Pros and cons?
What are Redis memory eviction strategies?
What are cache penetration/breakdown/avalanche? How to solve each?
What is the hot key problem? Impact? Solutions?
What is the big key problem? Impact? Solutions?
Do you understand Redis high availability? Master-slave? Sentinel? Redis cluster?
Besides the official solutions, do you know other Redis high availability solutions?
Do you understand the principle of master-slave data synchronization?
Is Redis AP or CP?
Does Redis support transactions?
Does Redis support transaction rollback?

Why Everyone Loves Putting Redis in Front of MySQL#

The Apple Notes section is very direct: Redis is often used as a MySQL cache because it simultaneously provides high performance and high concurrency.

MySQL’s main storage is on disk. Even with Buffer Pool, the average cost of random reads and writes is significantly higher than memory.
Redis puts hot data directly in memory, with short read paths and QPS far exceeding MySQL.
So many read requests shouldn’t go all the way to the database but should be blocked by Redis first.

Don’t answer this interview question as “Redis is fast, so use Redis.” A more solid answer is:

Redis is suitable for handling hot reads, temporary state, counters, leaderboards, short-term session information;
MySQL is responsible for true persistent primary storage;
When the two work together, the database handles fallback and eventual consistency, no longer directly bearing all high-frequency reads.

Differences Between Redis and Memcached#

This is also a high-frequency point from Apple Notes:

Similarities:

Both are memory-based databases;
Both can be used for caching;
Both support expiration;
Both have high performance.

Differences:

Memcached is basically pure key-value; Redis has much richer data structures.
Memcached doesn’t have Redis’s relatively complete persistence mechanism.
Memcached lacks Redis’s native clustering, pub/sub, Lua, transactions, and other capabilities.
Redis is more like an “in-memory data structure server” rather than just a cache box.

Redis Data Types and Use Cases#

Let’s look at the most common data types and scenarios together

Type	Common Scenarios
`String`	Cache objects, counters, distributed locks, shared sessions
`Hash`	Cache objects, shopping carts, user info with field-level reads
`List`	Simple message queues, timelines, deques
`Set`	Deduplication, likes, mutual follows, lottery
`ZSet`	Leaderboards, weighted sorting, delayed queues
`Bitmap`	Check-ins, login status, binary state statistics
`HyperLogLog`	UV, massive deduplication counting
`GEO`	Geographic location retrieval
`Stream`	More complete message queue semantics

What Are These Types Underneath#

String#

Both the original notes and Apple Notes mention SDS:

Binary-safe, not just for text;
Getting length is $O(1)$ because of the len field;
Checks space before concatenation, avoiding buffer overflow like C strings.

List#

Old materials often mention doubly linked lists / compressed lists;
Now it’s better to remember the quicklist + listpack approach.

You don’t need to memorize version details for interviews, but you should know: Redis switches between different implementations for “small and compact” vs “large and frequently changing” scenarios, not using hash tables for everything.

Hash#

Small objects are stored compactly;
Larger ones switch to actual hash table structures.

So it’s well-suited for caching objects, especially scenarios where “only a few fields of an object are updated.”

Set#

When all elements are integers and the scale is small, it uses integer sets;
Otherwise, it uses hash tables.

ZSet#

This part is often questioned: why is “skip list” often mentioned for the underlying implementation?

Because ZSet’s core requirement is two things happening simultaneously:

Fast lookup by member;
Ordered traversal and range queries by score.

So typically:

Hash table is used for member-to-score mapping;
Skip list is used for sorting by score and range operations.

Which Structures Most Commonly Appear in Business#

String: Cache detail pages, verification codes, counters.
Hash: User profiles, shopping carts.
Set: Deduplication relationships.
ZSet: Leaderboards, delayed tasks.
Bitmap: Check-in statistics.
HyperLogLog: UV.

Why Is Redis So Fast with Single Threading#

This question is easy to answer incorrectly. Apple Notes specifically emphasizes:

Redis’s “single-threaded” mainly refers to the main command path from receiving requests to executing commands and returning results being single-threaded.

It doesn’t mean the entire process has only one thread.

Redis’s Actual Thread Model#

Main thread: event loop, network I/O, command execution.
Background threads (BIO): handle time-consuming tasks like closing files, AOF flushing, lazy memory freeing.
After Redis 6: Can also enable I/O threads to share network send/receive pressure, but command execution is still single-threaded.

Why It’s Fast#

Following the order in the notes makes this smooth:

Most operations complete in memory;
Data structures specifically designed for high-frequency reads/writes;
Single-threaded command execution saves massive lock contention and thread switching;
Uses epoll I/O multiplexing, allowing one thread to monitor many connections.

So Redis’s bottleneck is often not CPU, but:

Memory;
Network bandwidth;
Big keys / hot keys;
Slow commands and unreasonable data structures.

Why Did Redis 6 Introduce I/O Threads#

Not because “single-threading doesn’t work anymore,” but because network I/O can sometimes become the bottleneck first.

So what Redis 6 does is:

Let multiple I/O threads share network read/write;
Actual command execution still goes to the main thread.

In other words, it optimizes “packet send/receive,” not changing the command execution model to multi-threaded concurrent execution.

Persistence: Redis Isn’t Just a Cache That Loses Data on Power Loss#

RDB#

RDB is snapshots:

At a certain point in time, dump all data in memory into a snapshot file;
Fast recovery;
Files are usually more compact;
But if it crashes between two snapshots, data in that window is lost.

AOF#

AOF appends write commands to a log.

Apple Notes emphasizes: Redis’s AOF records logs after executing commands.

Advantages:

Saves an extra step of command validity checking;
Current command execution path is more direct.

Cost:

If the command executes but AOF hasn’t been flushed to disk before a crash, data is still lost;
If AOF recording itself is on the main thread path, it may also affect subsequent commands.

Three Common Fsync Strategies#

appendfsync always: Flush to disk every write, most stable but slowest;
appendfsync everysec: Flush once per second, commonly used in practice;
appendfsync no: Let the OS decide when to flush.

Hybrid Persistence#

Starting from Redis 4.0, hybrid persistence is supported, which can be understood as:

First use RDB to load a large base state;
Then append incremental AOF.

This avoids pure AOF replay being too slow while losing less data than pure RDB.

How to Best Answer This Article#

If an interviewer asks in one sentence “Why is Redis suitable for caching,” I would follow this line:

In-memory storage, very fast for hot reads/writes;
Rich data structures, not just string lookups;
Simple command execution model, single-threading avoids lock contention;
Can do persistence, not just temporary caching;
Can extend to high availability, distributed locks, message queues, and other capabilities.

The next article will connect these more engineering-focused questions:

Distributed locks;
Message queues;
HyperLogLog;
Master-slave / Sentinel / Cluster;
Cache consistency.
